Camera Calibration Tool VAS6430/4 VAS6350 VAS721001

PART NAME:Camera Calibration Tool VAS6430/4 VAS6350 VAS721001

PACKING LIST;X1 kit
Shipment：EMS Fast delivery

      The radar module adaptation code has been installed for the reverse rearview, and the 5F 19 byte has been modified but the rearview has not been activated. Then, the flip code is 0184010162002017000040. Start the ODIS service version diagnostic program on the computer, select the 16 models of the Passat B8, select the no commission order, and wait for the diagnosis to be completed. In the network diagram, select the reverse camera, right-click the guidance mode, select the basic settings, and input the data according to the guidance mode. Align the calibration cloth, calibrate the camera height, and input it, Measure the distance from the rear wheel axle to the calibration cloth. Input the distance from the camera to the cloth. Generally, the placement distance from the rear wheel axle to the cloth is 1.2-1.8 meters, and then the next automatic calibration step is completed.
